Traffic Analysis F100 LAN Port

System: F100 in
Maintainer:
Description:lan 1 MATSUSAKA.NE.JP
ifType: ethernetCsmacd (6)
ifName:
Max Speed: 100.0 Mbits/s
Ip: 210.158.3.253 ()
The statistics were last updated Thursday, 20 September 2018 at 17:40,
at which time the device had been up for 7 days, 6:16:29.

`Daily' Graph (5 Minute Average)

day
Max Average Current
In 139.0 kb/s (0.0%) 9400.0 b/s (0.0%) 10.6 kb/s (0.0%)
Out 14.3 kb/s (0.0%) 6536.0 b/s (0.0%) 7984.0 b/s (0.0%)

`Weekly' Graph (30 Minute Average)

week
Max Average Current
In 5029.4 kb/s (0.6%) 23.0 kb/s (0.0%) 26.4 kb/s (0.0%)
Out 16.2 Mb/s (2.0%) 47.1 kb/s (0.0%) 7424.0 b/s (0.0%)

`Monthly' Graph (2 Hour Average)

month
Max Average Current
In 1265.0 kb/s (0.2%) 13.2 kb/s (0.0%) 9208.0 b/s (0.0%)
Out 4048.6 kb/s (0.5%) 16.7 kb/s (0.0%) 6880.0 b/s (0.0%)

`Yearly' Graph (1 Day Average)

year
Max Average Current
In 392.5 kb/s (0.0%) 13.2 kb/s (0.0%) 9136.0 b/s (0.0%)
Out 393.4 kb/s (0.0%) 7648.0 b/s (0.0%) 6440.0 b/s (0.0%)
GREEN ### Incoming Traffic in Bits per Second
BLUE ### Outgoing Traffic in Bits per Second
